High Quality PTFE Adhesive Fabric
$5 – $10/Square Meter
100 Square Meter (Min. Order)
“The PTFE tape is silicone adhesive coated on PTFE fabric (or pure PTFE membrane) which has been sodium treated on single side.”
Lead Time:
| Quantity(Square Meter) | 1 – 100 | > 1000 |
| Est. Time (days) | 5 | To be negotiated |
Specifications of PTFE Sheet Rolls Adhesive Heat Resistant Mesh Fabric:
| Part Number |
Overall Thickness (inches) | Coated Weight (lbs/yd2) |
Tensile Strength Warp/Fill (lbs/in) |
TearStrength Warp/Fill (lbs) |
Max.Width(mm) |
| Premium Grade | |||||
| 9039 | 0.0029 | 0.27 | 95/55 | 1.5/0.9 | 3200 |
| 9012 | 0.0049 | 0.49 | 150/130 | 2.5/2.0 | 1250 |
| 9015 | 0.006 | 0.6 | 150/115 | 2.1/1.8 | 1250 |
| 9025 | 0.0099 | 1.01 | 325/235 | 7.5/4.0 | 2800 |
| 9028AP | 0.011 | 1.08 | 320/230 | 5.4/3.6 | 2800 |
| 9045 | 0.0148 | 1.45 | 350/210 | 5.6/5.1 | 3200 |
| Standard Grade | |||||
| 9007AJ | 0.0028 | 0.25 | 90/50 | 1.7/0.9 | 1250 |
| 9010AJ | 0.004 | 0.37 | 140/65 | 2.6/0.7 | 1250 |
| 9011AJ | 0.0046 | 0.46 | 145/125 | 3.0/2.2 | 1250 |
| 9014 | 0.0055 | 0.54 | 150/140 | 2.0/1.5 | 1250 |
| 9023AJ | 0.0092 | 0.94 | 250/155 | 4.9/3.0 | 2800 |
| 9035 | 0.0139 | 1.36 | 440/250 | 7.0/6.0 | 3200 |
| 9065 | 0.0259 | 1.76 | 420/510 | 15.0/8.0 | 4000 |
| Mechanical Grade | |||||
| 9007A | 0.0026 | 0.2 | 80/65 | 2.3/1.0 | 1250 |
| 9010A | 0.004 | 0.37 | 145/135 | 2.3/1.6 | 1250 |
| 9021 | 0.0083 | 0.8 | 275/190 | 8.0/3.0 | 1250 |
| 9030 | 0.0119 | 1.14 | 375/315 | 7.0/6.0 | 2800 |
| Economy Grade | |||||
| 9007 | 0.0026 | 0.17 | 70/60 | 2.9/0.8 | 1250 |
| 9010 | 0.004 | 0.36 | 135/115 | 3.0/2.7 | 1250 |
| 9023 | 0.0092 | 0.72 | 225/190 | 4.4/3.2 | 2800 |
| 9018 | 0.0074 | 0.7 | 270/200 | 8.0/4.0 | 1250 |
| 9028 | 0.0112 | 0.98 | 350/300 | 15.0/11.0 | 3200 |
| 9056 | 0.0222 | 1.34 | 320/250 | 50.0/40.0 | 4000 |
| 9090 | 0.0357 | 2.04 | 540/320 | 10.8/23.0 | 4000 |
| Porous Bleeder & Filter | |||||
| 9006 | 0.0025 | 0.12 | 40/30 | 5.3/4.0 | 1250 |
| 9034 | 0.0135 | 0.77 | 175/155 | 21.0/12.0 | 3200 |
| Crease & Tear Resistant | |||||
| 9008 | 0.0032 | 0.31 | 90/50 | 1.6/0.5 | 1250 |
| 9011 | 0.0046 | 0.46 | 125/130 | 4.1/3.7 | 1250 |
| 9014 | 0.0056 | 0.52 | 160/130 | 5.0/3.0 | 1250 |
| 9066 | 0.0261 | 1.8 | 450/430 | 50.0/90.0 | 4000 |
| TAC-BLACK™ (Available anti-static) | |||||
| 9013 | 0.0048 | 0.45 | 170/140 | 2.2/1.8 | 1250 |
| 9014 | 0.0057 | 0.55 | 150/120 | 1.7/1.4 | 1250 |
| 9024 | 0.0095 | 0.92 | 230/190 | 4.0/3.0 | 2800 |
| 9024AS | 0.0095 | 0.92 | 230/190 | 4.0/3.0 | 2800 |
| 9037AS | 0.0146 | 1.39 | 405/270 | 8.5/7.2 | 3500 |
